Indoor Storage Tank
- Premium Quality Materials
- ISO Certified Production
- Custom Orders Available
Capacity: 100 L – 150000 L
Email:anxinde2011@163.com
Tel:+86-022-29300991
Equipment Features
Main Configuration
Equipment Features
Main Configuration
Equipment Features
The inner tank is made of high-quality SUS304-2B or SUS316L stainless steel.Inner tank plate thickness: δ=3–6 mm; outer cladding plate thickness: δ=2 mm.Honeycomb or coil jacket plate thickness: δ=1.5 mm.Double-layer tank with PU insulation, insulation thickness: 60–100 mm.
Single-layer, double-layer and jacketed tank types are available according to production process requirements.
Optional non-stirred or stirred design; agitator types include paddle type, anchor type, propeller type and frame type.
Main Configuration
Manhole with proximity switch monitoring, cleaning ball, positive and negative pressure breather,
liquid level switch, liquid level sensor, temperature sensor, sampling valve, safety guardrail, etc.
Equipment Features
The inner tank is made of high-quality SUS304-2B stainless steel.
Inner tank plate thickness: δ=3–6 mm; outer cladding plate thickness: δ=2 mm.
Honeycomb or coil jacket plate thickness: δ=1.5 mm; PU insulation thickness: 100 mm.
Main Configuration
Side-mounted agitator, side-mounted manhole, cleaning ball, breathing pipe, pressure sensor,
continuous liquid level display, high / medium / low liquid level switches, PT100 temperature sensor.
